Description
Parameters
| Size (L×W×H, propeller included) |
Unfolded: 2000 × 2000 × 800 mm Folded: 1050 × 1050 × 800 mm |
| Wheelbase | 2000 mm |
| Weight | |
|---|---|
| Aircraft Weight | 35 kg |
| Max. Payload | 50 kg |
| Max. Takeoff Weight | 96 kg |
| Performance | |
| Max. Flight Time | 50 min |
| Cruising Speed | 12 m/s |
| Max. Horizontal Speed | 20 m/s |
| Max. Ascent Speed | 3 m/s |
| Max. Descent Speed | 4 m/s |
| Max. Flight Altitude | 5000 m |
| Comm. & Nav | |
| Transmission Range | 20 km / 30 km |
| GNSS | GPS + GLONASS + BeiDou + Galileo |
| Environment | |
| Max. Wind Resistance | Level 6 |
| IP Protection Rating | IP44 |
| Operating Temperature | -20 ~ 60°C |
| Packaging | |
| Package Dimensions | 1200 × 1200 × 950 mm |
| Package Weight | 110 kg |
