Description
| Dimension | |
|---|---|
| Body length | 2580 mm |
| Wingspan | 4800 mm |
| Weight | |
| Aircraft Weight | 20 kg |
| Max. Payload | 20 kg |
| Max. Takeoff Weight | 55 kg |
| Performance | |
| Max. Flight Time | 180 min |
| Cruising Speed | 26 m/s |
| Max. Horizontal Speed | 40 m/s |
| Max. Ascent Speed | 3 m/s |
| Max. Descent Speed | 2.5 m/s |
| Max. Flight Altitude | 4500 m |
| Comm. & Nav | |
| Transmission Range | 80 km |
| GNSS | GPS+GLONASS+BeiDou+Galileo |
| Environment | |
| Max. Wind Resistance | Level 7 |
| IP Protection Rating | IP54 |
| Operating Temperature | -20~60℃ |
| Packaging | |
| Package Dimensions | Fuselage Box: 1810*980*720 mm Tail Box: 1800*460*1110 mm |
| Package Weight | Fuselage Box: 92 kg Tail Box: 39 kg |
