Description
| Dimension | |
|---|---|
| Body length | 1520 mm |
| Wingspan | 3478 mm |
| Weight | |
| Aircraft Weight | 9.5 kg |
| Max. Payload | 3 kg |
| Max. Takeoff Weight | 16 kg |
| Performance | |
| Max. Flight Time | 160 min |
| Cruising Speed | 210m/s |
| Max. Horizontal Speed | 35m/s |
| Max. Ascent Speed | 4 m/s |
| Max. Descent Speed | 3 m/s |
| Max. Flight Altitude | 4500 m |
| Comm. & Nav | |
| Transmission Range | 80 km |
| GNSS | GPS+GLONASS+BeiDou+Galileo |
| Environment | |
| Max. Wind Resistance | Level 6 |
| IP Protection Rating | IP54 |
| Operating Temperature | -20~60℃ |
| Packaging | |
| Package Dimensions | 1552*593*415 mm |
| Package Weight | 42 kg |
