Description
- Portable Ground Control Station
Parameters
| General Specs | |
|---|---|
| Battery Capacity | 13 Ah |
| Run Time | 4 hours |
| IP Protection Rating | IP54 |
| Operating Temperature | -20 ~ 60°C |
| Dimensions | 307.5 × 407.5 × 102 mm |
| Weight | 8.5 kg |
| Package Dimensions | 590 × 550 × 280 mm |
| Package Weight | 12.9 kg |
| Video Transmission | |
| Max. Transmission Distance | FCC: 20 km / CE / SRRC / MIC: 12 km |
| Operating Frequency | 2.4 GHz |
| Image Transmission | 720p@30fps / 1080p@60fps |
| Bit Rate | 500 kbps – 5 Mbps |
| Transmission Delay | < 30 ms |
| Reception Sensitivity | ≤ -89 dBm |
| Channels | 16 channels |
| Antennas |
1 × High-gain Fiberglass Antenna 1 × Directional Flat Panel Antenna |
| Control Screen | |
| Resolution | 1280 × 800 |
| Size | 12.1 inches |
| Brightness | 1500 nits |
| Touch Control | 10-point multi-touch |
